·This is a high end brightness colorful led strobe light, which is very suitable for the performance places.

Features

·High output power can reach 1000W;

·Equips RGBW SMD led light sources, which is very stable and good light output;

·Different DMX channel modes are optional which can used for different scene;

·The strobe power can reach 1500W max; keep 350W-1200W when full working.

Technical Specifications

Light Sources

·LED: 1320pcs RGBW SMD LEDs

·Lifespan: 50000h

·Color: RGBW color mixing

Optics

·Beam angle: 120degree

·Dimmer: 0-100% linear dimmer

·Strobe: 1-25 times/second

Light Output

·Illuminance: 14500 Lux at 1m

·Optimal projection distance: 3-45m

Control

·Control mode: DMX 512; Master and slave; Auto-run

·DMX channel: 4CH; 5CH; 7CH; 13CH; 15CH

·Display of control panel: digital tube + 4 buttons

Power Supply

·Related voltage: AC100V-240V, 50/60Hz

·Related power: 1000W

Construction

·Body dimension: D560*W230*H320mm

·Net weight: 12.5kg

·Shell color: black

·Shell material: aluminium die casting

Working Environment

·Working temperature: -25-40℃

·Cooling: Aluminum radiator, and mute Fan within 68db

·Protection rating: IP65

Equipment Optional Configuration

·Built-in battery: have the off-power setting ID address function

·Net work: artnet net work, can use the artnet signal control

Standard Configuration Spare Part List

·Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro standard, or other standard)

·User manual: English version user manual

·Clamp bridge: 1 set clamp bridge

Optional Configuration Spare Parts List

·Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)

·Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)

Package

·Flight case package size: 880*550*535mm(4pcs/case, with clamps space)

·N.W/G.W/V.W: 52kg/76kg/53kg

Selling Maintain Spare Parts List

·Switching power supply: VG-LST3000-P

·LED lamp board: VG-LST3000-L

·Main board: VG-LST3000-M
