Flat 725G
  • Flat 725G
  • Flat 725G
  • Flat 725G
  • Flat 725G
  • Flat 725G
  • Flat 725G
  • Flat 725G
  • Flat 725G

Model: Flat 725G

Name: 7pcs 25W RGBWA 5in1 LED Waterproof Light Walker

Product Model: Flat 725G
Commissioning Date: 2015-12
Sales Status: Selling
Reference Price:

·According to the needs of customers for external wall decorate beautification, we designed this light walker LED Par light. Its characteristic is high brightness, light beam is strong, can be used outdoors, energy conservation, environmental protection, is the choice of exterior wall decoration. The light is very suitable for outdoor stage lighting, wall decoration, bar exterior walls and other places.

Features

·5in1 LED Outdoor Par Light, many kinds color mixing;

·0-100% linear dimmer;

·High brightness, the beam can reach 30meters;

·Outdoor use, the IP rating can reach 65.

Technical Specifications

Light Sources

·LED: 7pcs 25W RGBWA 5in1 LED Lamp

·Lifespan: 50000hours

·Color: RGBWA 5in1 color mixing

Optics

·Beam angle: 20degree/30degree/60degree

·Grey grade: 256

·Dimmer: 0-100% linear dimmer

·Strobe: 1-25 times/second

Light Output

·Optimal projection distance: 4-10m

·Connection quantity: 22pcs under AC220V power input, 11pcs under AC220V power input

Control

·Control mode: DMX 512, Auto run, demo

·DMX channel: 5CH, 8CH

·Display of control panel: digital tube+4 buttons

Power Supply

·Related voltage: AC100V-240V, 50/60Hz

·Related power: related 140W

Construction

·Body dimension: 270*256*145mm(without handle), 270*256*310mm(with handle)

·Net weight: 6.2kg

·Shell color: black

·Shell material: dia-casting aluminum

Working Environment

·Working temperature: -25-40℃

·Cooling: aluminum radiator + dia-casting aluminum surface

·Protection rating: IP65

Standard Configuration Spare Part List

·Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro standard, or other standard)

·User manual: English version user manual

Optional Configuration Spare Parts List

·Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)

·Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)

Package

·Carton board box package size: 430*380*240mm(1pc/carton)

·N.W/G.W/V.W: 6.2kg/7.5kg/8kg

·Carton board box package size: 750*460*460mm(4pc/carton)

·N.W/G.W/V.W: 28kg/30kg/32kg

·Flight case package size: 480*600*780mm(6pcs/flight case)

·N.W/G.W: 40kg/59kg

·Flight case package size: 910*600*780mm(12pcs/flight case)

·N.W/G.W: 84kg/110kg

Selling Maintain Spare Parts List

·Switching power supply: Flat 725G-P

·LED lamp board: Flat 725G-L

·Main board: Flat 725G-M

·Drive board: Flat 725G-D
