Technical Specifications

Light Sources

·LED: 864pcs 0.4W RGB SMD

·Lifespan: 50,000 hours lifespan, low power consumption

·Color: RGB 3in1 color mixing

·Color temperature: 6500-7500K

Optics

·Beam angle: 120degree

·Dimmer: 0-100% linear dimmer

·Strobe: 0-30 times/second

·Effect: 18 blocks individual controlled, can make hundreds of special effect

Light Output

·Optimal projection distance: 3-10m

Control

·Control mode: DMX 512; Master and slave; Auto-run; Sound active

·DMX channel: 5CH/13CH/54CH

·Display of control panel: LCD display + 4 buttons

Power Supply

·Related voltage: AC90V-240V, 50/60Hz

·Related power: 350W(max)

Construction

·Body dimension: D450*W230*H300mm

·Net weight: 6.8kg

·Shell color: black

·Shell material: Flame-proof Plastic

Working Environment

·Working temperature: -25-40℃

·Cooling: Sebsor thermostat controlled veriable speed fan

·Protection rating: IP20

Standard Configuration Spare Part List

·Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro standard, or other standard)

·User manual: English version user manual

Optional Configuration Spare Parts List

·Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)

·Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)

Package

·Carton board box package size: 540*240*340mm(1pc/carton)

·N.W/G.W/V.W: 7.5kg/9kg/9kg

Selling Maintain Spare Parts List

·Switching power supply: VG-LST854CC-P

·LED lamp board: VG-LST854CC-L

·Main board: VG-LST854CC-M

·Drive board: VG-LST854CC-D
